Video Wall Panels (Indoor and Outdoor)

The customized video walls are perfect for events, office conference rooms and overall
brand promotion. With eye-catching image quality, vivid colors and a creative design, our units turn heads using the most innovative technology on the market.
Using quick connect technology, completely customize a seamless video wall experience,
creating endless advertising possibilities, all while controlling content from your phone.

***Please note: Pricing is $295.00 per Square Foot

Module Specifications:

• Pixel Pitch: 2.96mm
• Module Size: 250mm × 250mm
• Module Resolution: 84x84 dots
• Color Configuration: SMD 3in1 1R1G1B
• Pixel Density: 112896 dots/m2
• Driver Mode: 1/28 Scan

Standard Cabinet Specifications:

• Cabinet Size(WXH): 500mm W x 500mm H
• Cabinet Resolution: 168x168 Pixels /dots
• Module Quantity: 4 pcs
• Pixel Density: 112896 dots/m2
• Average Power Consumption: 400W/m2
• Max. Power Consumption: 800W/m2
• Frame Material: Die-Cast Aluminum
• Cabinet Weight: 7.5KG/Piece

Screen Parameters:

• Controlling System: NovaStar
• Refresh rate: 3840hz
• Power Supply: 5V 40A 110-220V
• Viewing Angle: Horizontal 140°, Vertical 140°
• Min. Viewing Distance: ≥ 3 meter
• Gray scale: 8192×8192×8192
• Brightness: 800-1200 cd/m²
• Colors: 549 Billion
• Input Voltage: AC220V/50Hz or AC110V/60Hz
• MTBF: >10,000 hours
• Life span: ≥100,000 hours

• IP rating(Front/Rear): IP31
• Temperature Operating: -10°C~60°C
• Humidity Operating: 10%~90%
